Belt for Bolens 1737459, Cub Cadet 754-3029 or 954-3029, EverRide 192111, John Deere M117608, MTD754-0245 or 954-0245, Murray 37X24 or 37X24MA or Scag

Belt Replaces:

Bolens   1737459
Cub Cadet   754-3029 or 954-3029
EverRide   192111
John Deere   M117608
MTD   754-0245 or 954-0245
Murray  37X24 or 37X24MA
Scag   481749

___________________________________________________________

Fits:

Bolens
1113 LT11 as the cutter deck belt

Cub Cadet
38", 44", 46" cut   12hp to 15hp models as the PTO belt

EverRide
48" cut   Hornet 20/48D  ZTR as the pump drive belt
52" cut   Hornet 20/52D (Diesel) ZTR as the pump drive belt

John Deere
38" cut   LX277, LX279 as the engine to PTO belt

MTD
42" cut   16hp LGT 1655 as the transmission belt

Murray
36" cut   16hp 5 speed model 36207 as the cutter belt

Scag
Selected Turf Tiger as the pump drive belt

___________________________________________________________

Belt Details:

Width: (inches) 1/2" (mm): 12.7mm
Inside circumference (inches) 57" (mm): 1447mm
Outside circumference (inches) 59" (mm): 1498mm
(Non-genuine)
Made with KEVLAR™

Please check your manual for the correct belt number as there could be multiple applications.
Manufacturers have uploaded manuals online.

All parts need to be fitted by a licensed Technician

• High quality aftermarket replacement belt
• Certified in manufacture ISO/TS16949:2016 and ISO 14001 OHSAS 18001
• PIX belts meet the 'essential' Health and Safety norms for its entire range of fire-resistant, anti-static belt
